High Precision Hard Jaws & Soft Jaws

HJ Series

Standard Hard Jaw

E-CATALOG ADD TO INQUIRY

Specification

-Made of hardened steel (heat-treated).
-Cannot be re-machined but ideal for gripping raw materials.
-A reliable choice for standardized parts production and heavy-duty cutting.

Dimensions

Dim / Model	HJ-05	HJ-06	HJ-08	HJ-10	HJ-12	HJ-12-1	HJ-15	HJ-15-1	HJ-21
J-1	53	67.5	86	99.5	103	103	149	149	165
J-2	23	32	35	40	50	50	62	62	65
J-3	27.5	35	51	54	52	52	86	86	90
J-4	10	12	14	16	21	18	22	25.5	25
J-5	4	5	5	5	5	5	8	5	9
J-6	30.5	39	31	43	62.5	62.5	63	63	104.5
J-7	14	20	25	30	30	30	43	43	50
J-8	25.5	28.5	18	17	40.5	40.5	34	34	55
J-9	13.5	17	19	19	25	22	32	32	32
J-10	8.5	11	13	13	17	15	21	21	21
J-11	10	12	12	13	17	17	20	20	20
J-12	M8	M10	M12	M12	M16	M14	M20	M20	M20
J-13	6	10	12	15	30	30	40	40	55
Serration	1.5x60°	1.5x60°	1.5x60°	1.5x60°	1.5x60°	1.5x60°	1.5x60°	1.5x60°	3.0x60°
Reference	B	B	A	A	B		A		B
