V Series

3-Jaw Wedge Type Non Through-Hole Power Chuck
(Without Adaptor)

E-CATALOG ADD TO INQUIRY

Specification

-Standard JIS chuck for CNC lathe.
-Suitable for all kinds of turning machining.

Spec. \ Model	V-206	V-208	V-210	V-212	V-215	V-218	V-221	V-224
Jaw Stroke (Dia.) (mm)	8.5	8.8	8.8	10.5	16	16	16	16
Plunger Stroke (mm)	20	21	25	30	35	35	35	35
Max. Clamping Dia. (mm)	165	210	254	304	381	450	530	610
Min. Clamping Dia. (mm)	12	12	16	18	68	40	50	50
Max. Rotation Speed (r.p.m.)	5000	4000	3500	3000	2800	2700	1900	1750
Max. Draw Bar Pull Force kN(kgf)	1835	2549	2957	4181	8362	8362	8362	8362
Max. Clamping Force (kgf) / (kgf/cm²)	5253 / 25.5	7548 / 24.5	11013 / 28.6	15807 / 27.5	25391 / 32.6	25391 / 32.6	25391 / 32.6	25391 / 32.6
Moment of Inertia (kg⋅m²)	0.045	0.137	0.3	0.725	1.8	2.35	4.8	6.92
Weight (KG)	12	22.8	34.4	59	100.6	126	187	225
Matching Hydraulic Cylinder	MH-105	MH-125	MH-125	MH-150	MH-200	MS-200	MS-200	MS-200
Matching Hard Jaw	HJ-06	HJ-08	HJ-10	HJ-12-1	HJ-15-1	HJ-15-1	HJ-21-1	HJ-21-1
Matching Soft Jaw	HC-06	HC-08	HC-10	HC-12-1	HC-15-1	HC-15-1	HC-21-1	HC-21-1

Dimensions

Dim \ Model	V-206	V-208	V-210	V-212	V-215	V-218	V-221	V-224
A	165	210	254	304	381	450	530	610
B	74	85	89	106	114	114	125	125
K H6	140	170	220	220	300	300	380	380
M	5	5	5	6	6	6	6	6
C	104.78	133.35	171.45	171.45	235	235	330.2	330.2
P	21	25	34	34	-	-	-	-
L	6-M10	6-M12	6-M16	6-M16	6-M20	6-M20	6-M24	6-M24
N	14	20	18	22	29	29	31	31
F	20	25	30	30	43	43	60	60
Q Max.	37.8	46.3	51.1	61	77.5	108	86.5	125
Q Min.	33.55	41.9	46.7	55.75	69.5	100	78.5	117
E Max.	18	22.5	37.5	47	50.25	93	93	93
E Min.	7.5	9	10.5	11	23.25	24	24	24
H Max.	104.6	132	158	163	104	92	97	97
H Min.	84.6	111	133	133	69	57	62	62
S	12	14	16	18	25.5	25.5	25	25
R	31	35	40	50	50	50	65	65
J	M16x2.0	M20x2.5	M20x2.5	M20x2.5	M30x3.5	M30x3.5	M30x3.5	M30x3.5
O	34	38	45	50	60	60	60	60
I	36	36	36	36	55	55	55	55
