High Speed Through Hole Hydraulic Cylinder

RC Series

High Speed Through-hole Rotary Hydraulic Cylinder

E-CATALOG ADD TO INQUIRY

Specification

Spec. \ Model	RC-4	RC-5	RC-6S	RC-6	RC-8S	RC-8	RC-10S	RC-10	RC-10X	RC-12	RC-15	RC-2814	RC-2816
Effective Piston Area (cm²) Extend	47	67	100	100	161	161	198	198	198	252	345	397.2	397.2
Effective Piston Area (cm²) Retract	41.5	64.5	89	89	150	150	183	183	183	234	336	354.3	354.3
Piston Stroke (mm)	9	15	15	15	22	22	25	25	25	30	23	42	42
Max. Speed (r.p.m)	8000	8000	8000	7000	6200	6200	4700	4700	4700	3800	2800	2000	2000
Max. Pressure (kgf / cm²)	40	40	40	40	40	40	40	40	40	40	40	33	33
Moment of Inertia (kgf·m²)	0.01	0.013	0.029	0.029	0.045	0.045	0.09	0.029	0.029	0.16	2.34	1.079	0.842
Weight (kg)	5.6	8.6	12.3	12	17	16.8	27	26.5	26	33	55	98.9	84.3
Max. oil leakage from drain port and max. internal oil leakage (lit / min)	3	3	3	3	3.9	3.9	4.2	4.2	4.2	4.5	7	9.5	9.5

Dimensions

Dim \ Model	RC-4	RC-5	RC-6S	RC-6	RC-8S	RC-8	RC-10S	RC-10	RC-10X	RC-12	RC-15	RC-2814	RC-2816
C	115	135	155	155	190	190	215	215	215	240	310	340	340
D	100	115	130	130	170	170	190	190	190	215	275	280	280
E	80	100	100	100	130	130	160	160	160	180	230	-	-
F	65	65	80	80	85	85	120	120	120	140	166	240	240
G	44	48	65	65	70	70	95	95	95	110	140	190	190
H	M38x1.5	M42x1.5	M55x2	M55x2	M55x2	M60x2	M75x2	M85x2	M87x2	M100x2	M130x2	M158x3	M180x3
J	28	36	36	46	46	52	68	75	78	91	117.5	145	166.5
K	25	30	36	36	36	36	36	36	36	36	36	30	30
M	35	44.8	52.9	52.9	59.4	59.4	84.6	84.6	84.6	99.6	118	178	178
N	44	55	64	64	73	73	98	98	98	108	148	190	190
P	59	73	85	85	96	96	121	121	121	138	178	218	218
S	90	106	118	118	137	137	166	166	166	182	225	285	285
T	105	115	115	115	130	130	160	160	160	185	215	250	250
U	158	175.5	184	184	196	196	230	230	230	253	267	279	279
V Max.	9	10	10	10	17	17	20	20	20	25	18	41	41
V Min.	0	-5	-5	-5	-5	-5	-5	-5	-5	-5	-5	-1	-1
W Max.	34	40	40	40	47	47	50	50	50	50	56	75	75
W Min.	25	25	25	25	25	25	25	25	25	25	33	33	33
Z	5	5	5	5	5	5	5	5	5	5	5	-	-
A	76	88	98	98	110	110	155	155	155	165	206	260	260
A1	9.5	11	11.5	11.5	12	12	17.5	17.5	17.5	21	21	13.5	13.5
B1	106	120.5	126.5	126.5	136	136	153.5	153.5	153.5	168	153.5	202	202
C1	25	25	30	30	30	30	35	35	35	35	45	45	45
E1	M6x10	M5x9	M6x9	M6x9	M6x9	M6x9	M6x9	M6x9	M6x9	M6x14	M6x10.5	M6x10.5	M6x10.5
F1	M8x20	M10x20	M10x20	M10x20	M10x20	M10x20	M10x20	M10x20	M10x20	M12x24	M16x24	M16x30	M16x30
G1	114.5	126.5	135	135	145	145	166.5	166.5	166.5	183	197	216	216
J1	60	66	76	76	86	86	101	101	101	110	129	163	163
K1	47	47	47	47	47	47	47	47	47	47	55	67	67
L1	15	15	15	15	15	15	15	15	15	15	20	150	150
M1	30	38	50	50	50	55	76	80	82	95	123	150	170
N1	53	64	76	76	85	85	108	108	108	120	160	174.5	174.5
P1	4	4	4	4	4	4	4	4	4	4	5	5	5
Q1	M4x10	M5x10	M5x10	M5x10	M6x12	M6x12	M6x12	M6x12	M6x12	M6x12	M6x12	M6x12	M6x12
R1	5	5	6	6	7	7	7	7	7	7	7	7	7
S1	PT 3/8	PT 3/8	PT 1/2	PT 1/2	PT 1/2	PT 1/2	PT 1/2	PT 1/2	PT 1/2	PT 1/2	PT 1/2	PT 1/2	PT 1/2
T1	6	6	6	6	6	6	6	6	6	6	6	6	6
W1	M34x1.5	M44x1.5	M52x1.5	M52x1.5	M58x1.5	M58x1.5	M84x2.0	M84x2.0	M84x2.0	M99x2.0	M134x2.0	M177x2.0	M177x2.0
X1	32	42	50	50	56	56	81	81	81	96	131	174.5	174.5
