| Spec. \ Model | RM-06 | RM-06S |
|---|---|---|
| Effective Piston Area (cm²) Extend | 100.6 | 100.6 |
| Effective Piston Area (cm²) Retract | 89.5 | 89.5 |
| Piston Stroke (mm) | 15 | 15 |
| Max. Speed (r.p.m) | 7000 | 7000 |
| Max. Pressure MPa (kgf / cm²) | 4.0 (40.8) | 4.0(40.8) |
| Moment of Inertia (kgf·m²) | 0.019 | 0.020 |
| Weight (kg) | 8.5 | 9.0 |
| Max. oil leakage from drain port and max. internal oil leakage (lit / min) | 3 | 3 |
| Dim \ Model | RM-06 | RM-06S |
|---|---|---|
| A | 165 | 165 |
| B | 147 | 147 |
| C | 130 | 130 |
| D | 100 | 100 |
| E | 65 | 65 |
| F | M55x2 | M50x1.5 |
| G | 46 | 43 |
| H | 50 | 50 |
| I | M52x1.5 | M52x1.5 |
| J | 118 | 118 |
| K | 29.5 | 29.5 |
| L | 15 | 15 |
| M1 | 50 | 50 |
| M Max. | 13.5 | 13.5 |
| M Min. | -1.5 | -1.5 |
| N | 153 | 153 |
| O Max. | 26 | 26 |
| O Min. | 41 | 41 |
| P | 5 | 5 |
| Q | 69 | 69 |
| R | 50 | 50 |
| S | 120.5 | 120.5 |
| T | 59 | 59 |
| U | 62 | 62 |
| V | 4-M5x6 | 4-M5x6 |
| W | PT 3/8" | PT 3/8" |
