Specification
Dimensions
| Dim / Model | CL44-A5 |
|---|---|
| Steel Collet | C44 |
| A | 135 |
| B | 104.8 |
| C | 82.56 |
| D | M70xP1.5 |
| E | 62 |
| F | M55xP2 |
| G | 30 |
| K | 23 |
| M Max. | 27 |
| M Min. | 22 |
| N | 27 |
| d | 44 |
| O | 113 |
| L | 121 |
| P | 4-M10x30 |
| Q | 8 |
Collet Chuck
| Dim / Model | CL44-A5 |
|---|---|
| Steel Collet | C44 |
| A | 135 |
| B | 104.8 |
| C | 82.56 |
| D | M70xP1.5 |
| E | 62 |
| F | M55xP2 |
| G | 30 |
| K | 23 |
| M Max. | 27 |
| M Min. | 22 |
| N | 27 |
| d | 44 |
| O | 113 |
| L | 121 |
| P | 4-M10x30 |
| Q | 8 |
