Specification
Dimensions
| Dim / Model | CL26-A4 | CL30-A4 | CL36-A5 | CL42-A5 | CL42-A6 | CL52-A5 | CL52-A6 | CL60-A6 | CL60-A8 | CL80-A8 |
|---|---|---|---|---|---|---|---|---|---|---|
| Max. Speed | 7000 | 7000 | 6000 | 6000 | 6000 | 6000 | 6000 | 5000 | 5000 | 4000 |
| Steel Collet | 161E | 163E | 171E | 173E | 173E | 177E | 177E | 185E | 185E | 193E |
| A | 112 | 112 | 135 | 135 | 170 | 135 | 170 | 170 | 220 | 220 |
| B | 82.6 | 82.6 | 104.8 | 104.8 | 133.4 | 104.8 | 133.4 | 133.4 | 171.4 | 171.4 |
| C | 63.5 | 63.5 | 82.56 | 82.56 | 106.36 | 82.56 | 106.36 | 106.36 | 139.7 | 139.7 |
| D | M50xP1.5 | M50xP1.5 | M66xP1.5 | M66xP1.5 | M66xP1.5 | M70xP1.5 | M90xP1.5 | M90xP1.5 | M90xP1.5 | M114xP2.0 |
| E | 45 | 45 | 62 | 62 | 66 | 62 | 66 | 66 | 90 | 108 |
| F | M40xP1.5 | M40xP1.5 | M55xP2.0 | M55xP2.0 | M60xP2.0 | M55xP2.0 | M60xP2.0 | M60xP2.0 | M85xP2.0 | M100xP2.0 |
| G | 20 | 20 | 30 | 30 | 30 | 30 | 30 | 30 | 30 | 30 |
| K | 23 | 23 | 23 | 23 | 23 | 23 | 31 | 31 | 31 | 31 |
| M Max. | 21.5 | 21.5 | 26 | 26 | 29 | 26 | 33 | 33 | 33 | 34 |
| M Min. | 16.5 | 16.5 | 21 | 21 | 24 | 21 | 28 | 28 | 28 | 29 |
| N | 30 | 30 | 27 | 27 | 32 | 27 | 27 | 27 | 37 | 35 |
| d | 26 | 30 | 36 | 42 | 42 | 52 | 52 | 60 | 60 | 80 |
| O | 87 | 87 | 103 | 103 | 103 | 113 | 132 | 132 | 132 | 155 |
| L | 110 | 110 | 129 | 129 | 133 | 129 | 155 | 155 | 155 | 175 |
| P | 3-M10x30 | 3-M10x30 | 4-M10x30 | 4-M10x30 | 4-M12x30 | 4-M10x30 | 4-M12x30 | 4-M12x30 | 4-M16x35 | 4-M16x35 |
| Q | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 8 | 11 |
