High Precision Hard Jaws & Soft Jaws

HC Series

Standard Soft Jaw

E-CATALOG ADD TO INQUIRY

Specification

- Non-heat-treated and consumable part.
- Can be machined to match the shape of the workpiece to improve clamping precision.
- Ideal for irregularly shaped parts and fine finishing. Widely used in high-accuracy manufacturing.

Dimensions

Model	HC-04	HC-05	HC-06	HC-08	HC-10	HC-12	HC-12-1	HC-15	HC-15-1	HC-21
J-1	49.5	54	66	95	110	130	130	165	135	185
J-2	23	23	32	35	40	50	50	62	50	62
J-3	23	25	28	38	42	50	50	62	60	70
J-4	10	10	12	14	16	21	18	22	25.5	25
J-5	4	4	5	5	6	6	6	8	5	9
J-6	10	12	12	24	30	39	39	37	26	40
J-7	14	14	20	25	30	30	30	43	43	60
J-8	25.5	28	34	46	50	60	60	85	66	85
J-9	13.5	13.5	17	19	19	25	23	32	32	32
J-10	8.5	8.5	11	13	13	17	15	21	21	21
J-11	14	16	16	23	27	30	30	38	39	46
J-12	M8	M8	M10	M12	M12	M16	M14	M20	M20	M20
J-13	4	5	5	12	18	18	18	-	-	-
J-14	-	-	12	20	20	30	30	-	-	-
Serration	1.5x60°	1.5x60°	1.5x60°	1.5x60°	1.5x60°	1.5x60°	1.5x60°	1.5x60°	1.5x60°	3.0x60°
