Non Through-Hole Rotary Hydraulic Cylinder

MH Series

Non Through-Hole Rotary Hydraulic Cylinder
MH
E-CATALOG ADD TO INQUIRY
Specification
Made of high-grade aluminum alloy, it is compact and lightweight, reducing the burden on the machine spindle.
Due to its compact and lightweight design, it is highly precise and suitable for high-speed applications.
Spec. \ ModelMH-75MH-105MH-125MH-150MH-200
Piston Stroke
(mm)		1520253035
Effective Piston Area
Push Side (cm²)		4486122176314
Effective Piston Area
Pull Side (cm²)		3981115160290
Max. Draw Bar Pull Force
KN (kgf)		15.5 (1560)32 (3240)46 (4600)63 (6424)113 (11523)
Max. Operating Pressure
MPa (kgf / cm²)		4.0 (40.8)4.0 (40.8)4.0 (40.8)4.0 (40.8)4.0 (40.8)
Total Leakage
(l / min)		0.80.80.80.80.8
Max. Speed
(r.p.m.)		60006000600055005500
Weight
(KG)		3.66.3912.521
Moment of Inertia
N.m (kgf.m²)		0.108 (0.011)0.39 (0.04)0.88 (0.09)1.86 (0.19)3.82 (0.39)
Dimensions
Dim \ ModelMH-75MH-105MH-125MH-150MH-200
A75105125150200
B1520253035
C115135160190245
D90100130130145
E6580110110120
F3030354555
G2121253137
HM20x2.5M20x2.5M24x3.0M30x3.5M36x4.0
J3535444560
K147170178187203
L668997106122
M102125133142158
N Max.4645515669
N Min.3125262634
P6-M8x1.256-M10x1.56-M12x1.7512-M12x1.7512-M16x30
Q108131139148164
