- Collects cutting fluid during machining and returns it to the oil tank via drain pipe.
- Can be equipped with a detection mechanism to monitor stroke.
- Can be equipped with a detection mechanism to monitor stroke.
Specification
Dimensions
| Dim / Model | CM8B | CM10B | CM12B | CM15B | CM18B | CM20B | CM25B | CM30B |
|---|---|---|---|---|---|---|---|---|
| A | 78 | 78 | 118 | 158 | 158 | 158 | 198 | 265 |
| B | 61 | 75 | 87 | 98 | 123 | 140 | 180 | 218 |
| C | 42 | 42 | 42 | 44 | 44 | 44 | 44 | 49 |
| D | 84 | 84 | 88.5 | 88.5 | 88.5 | 88.5 | 105 | 101 |
| E | 115 | 115 | 131 | 151 | 151 | 151 | 215 | 250 |
| F | 60.5 | 60.5 | 76 | 96 | 96 | 96 | 126 | 148 |
| G | 90 | 90 | 107 | 147 | 147 | 147 | 200 | 237 |
| H | 6 | 6 | 6 | 6 | 6 | 6 | 6 | 6 |
| I min | 22 | 22 | 23 | 23 | 23 | 22.5 | 25 | 25 |
| Matching Hydraulic Cylinder | RC-4 | RC-5 | RC-6 | RC-8 | RC-10 | RC-12 | RC-15 | RC-2814 RC-2816 |
