The collet chuck CL52-A6D is a new product designed for industry 4.0 which is a workholding suitable for automatic turning and milling center. This workholding is wear resisting, compact and less tool interference (between the tool holder and the part receiver). Those features make CL52-A6D the best accessory during turning and milling machining.
Specification
Dimensions
| Dim / Model | CL52-A6D |
|---|---|
| Max. Speed | 6000 |
| Steel Collet | 177E |
| A | 170 |
| B | 133.4 |
| C | 106.36 |
| D | M70xP1.5 |
| E | 66 |
| F | M60xP2 |
| G | 30 |
| K | 30 |
| M Max. | 43 |
| M Min. | 38 |
| N | 32 |
| d | 52 |
| O | 113 |
| L | 145 |
| P | 4-M12x35 |
| Q | 8 |
